| SPECIFICATIONS | Unit | VT-8 |
| CAPACITY |
|---|
| Swing over Z way cover | mm(inch) | 320(12.6") |
| Max. turning diameter | mm(inch) | 120 (4.72") |
| Swing over cross slide | mm(inch) | 120 (4.72”) |
| Max. turning length | mm(inch) | 90(3.54") |
| TRAVEL |
|---|
| X-axis travel | mm(inch) | 210(8.26") |
| Z-axis travel | mm(inch) | 180(7.08") |
| SPINDLE |
|---|
| Type of spindle nose | ISO | A2-4 |
| Chuck diameter | mm(inch) | 125(5") |
| Spindle bearing inner diameter | mm(inch) | 65 (2.6”) |
| Through spindle hole diameter | mm(inch) | 35 (1.4”) |
| Through bar capacity | mm(inch) | 26 (1”) |
| Spindle drive motor(cont/30min) | KW (Hp) | 3.75 (5) |
| Spindle speed range | rpm | 6000 |
| TURRET |
|---|
| Number of tool stations |
|
|
| Turret type |
| GANG TYPE |
| Turret indexing time | sec |
|
| Shank height of square tool | mm(inch) | 12 (1/2”) |
| Shank diameter for boring bar | mm(inch) | 20 (3/4”) |
| FEEDRATE |
|---|
| Rapid traverse rate X-axis | mm/min | 15000 |
| Rapid traverse rate Z-axis | mm/min | 15000 |
| Ballscrew diameter of X-axis | mm(inch) | 20*P5 |
| Ballscrew diameter of Z-axis | mm(inch) | 25*P5 |
| TAILSTOCK |
|---|
| Tailstock travel | mm(inch) |
|
| Tailstock spindle diameter | mm(inch) |
|
| Tailstock spindle travel | mm(inch) |
|
| Taper hole of tailstock spindle |
|
|
| REMARKS |
|---|
| Coolant pump motor | Kw (Hp) | 0.2 (1/4) |
| Coolant tank capacity | L | 160 |
| Floor space | mm(inch) | 1530*1310(60.2"*52") |
| Machine weight | Kg (lb) | 1850 (4070) |
